1) Specification of the power plug
(1) Single phase 100V~120V
(2) Single phase 200V~240V
(3) Three phase 200V~240V
※Be sure to connect Protective Earth
2) Specification of electric current in wiring of power plug
Be sure to use wiring materials which can stand electric current of higher than 15A.
WIRING AND GROUNDING
55
110V
220V
220V
EARTHV
EARTHV
EARTHV
Switch Box
Control Box
Control Box
Control Box
Switch Box
Switch Box
To Next Page
