SunStar KM-235 User Manual

99
Ref. No. Parts No. Note Name of Parts 품 명 Q’ty
Applied
Period
C1-1 EA-000779-00 S/V5 single-phase 110V(SIMPLE) S/V5 단상 110V(SIMPLE) 1
C1-2 EA-000778-00 S/V5 single-phase(three-phase) 220V(SIMPLE) S/V5 단상(삼상) 220V(SIMPLE) 1
C1-3
BD-001029-04 S/V5 POWER REV04 SIMPLE B/D 220V/380V S/V5 POWER REV04 SIMPLE B/D 220V/380V 1(Ass’y) Aug.24.12
BD-001030-03 POWER REV04 (F-5 SIMPLE 110V) POWER REV04 (F-5 SIMPLE 110V) 1(Ass’y) Aug.24.12
BD-001030-02 POWER REV04 (F-5 SIMPLE 110V) POWER REV04 (F-5 SIMPLE 110V) 1(Ass’y) Jul.26.12
C1-3-1 11-007B-SE55 Power input cable(SE0010) 전원 입력케이블(SE0010) 1
C1-3-2 09-003A-SC51 Bridge diode 3510 브릿지다이오드 3510 2
C1-4 BD-001028-03 Digital Rev5C(F5-SIMPLE CPU)B/D Digital Rev5C(F5-SIMPLE CPU)B/D 1(Ass’y) Jun.21.13
C1-5-1 03-000A-SE55 S/V 5 OP BOARD ASS°ØY S/V 5 OP BOARD ASS’Y 1
C1-5-2 10-006A-SE55 Control box display panel 콘트롤박스 디스플레이패널 1
C1-5-3 GP-024775-01 Display panel membrane (S5) 디스플레이 패널 맴브레인(S5) 1
C1-5-4 11-002B-SE55 Control panel cable SE-2 조작반케이블 SE-2 1
C1-5-5 11-001B-SE55 Control panel cable SE-1 조작반케이블 SE-1 1
C1-6 GP-013914-00 Control box 콘트롤 박스 1
C1-7 GP-014578-00 Control box front cover (simple) 콘박스 전면커버 단순 1
C1-8 GP-014579-00 Box back cover -S/V5 박스 후면커버-S/V5 1
C1-9 GP-024746-00 S/V5 front sticker S/V5 전면스티커 1
C1-10 GP-053194-00 SIMPLE TYPE side cover(left)-on the side of connector SIMPLE TYPE 측면커버(좌)-콘넥터측 1
C1-11 GP-014584-00 Side cover (right) 측면커버(우) 1
C1-12 GP-013180-00 Control box holder(new model) 콘트롤박스홀더신형 1
C1-13 GP-011331-02 Model sticker(S/V SERIES) 모델 스티커(S/V SERIES) 1
C1-14 GP-011049-01 Warning sticker(English, Korean, Spanish, Chinese) 경고스티커(영,한,스페인,중문) 1
C1-15 10-003C-SE55 Cable rubber guide C 케이블고무가이드 C 1
C1-16 SC-000468-00 STUD PCB support(4-5-15) STUD PCB 받침(4-5-15) 5(Ass’y)
C1-17 10-011C-SE55 Option sticker 옵션스티커 1
C1-18 12-005B-SE55 Auxiliary signal cable SE-008 보조신호 케이블 SE-008 1
C1-19 CA-002483-00 Motor output cable SE-011 모터출력 케이블 SE-011 1
C1-20 10-002S-SW66 Set screw M3*L8(SP8) SET나사 M3*L8(SP8) 4(Ass’y)
C1-21 CA-002487-00 DC power cable SE-007 직류전원 케이블 SE-007 1
C1-22 10-002S-SW66 Set screw M3*L8(SP8) SET나사 M3*L8(SP8) 4(Ass’y)
C1-25 09-007A-HB10 Asbestos resistance 160ohm 40W HB 석면저항160옴40W HB 1
C1-26 11-015B-SE55 Resistance connector cable SE-017 저항콘넥터 케이블 SE-017 1
C1-26-1 10-002S-SW66 Set screw M3*L8(SP8) SET나사 M3*L8(SP8) 1
C1-27 PSC-BH000300 Small truss screw[M4xP0.7, L=8, Cr plating(polished shiny)] 트러스 작은나사 [M4xP0.7, L=8, Cr도금(유광)] 4(Ass’y)
C1-29 PSC-BH000300 Small truss screw[M4xP0.7, L=8, Cr plating(polished shiny)] 트러스 작은나사 [M4xP0.7, L=8, Cr도금(유광)] 2(Ass’y)
C1-30 PSC-BH000300 Small truss screw[M4xP0.7, L=8, Cr plating(polished shiny)] 트러스 작은나사 [M4xP0.7, L=8, Cr도금(유광)] 2(Ass’y)
C1-31 PSC-BH000300 Small truss screw[M4xP0.7, L=8, Cr plating(polished shiny)] 트러스 작은나사 [M4xP0.7, L=8, Cr도금(유광)] 4(Ass’y)
C1-32 07-027S-SE55 Set screw M5*L10(white zinc) SET나사 M5*L10(백색아연) 4(Ass’y)
C1-33 SC-000468-00 STUD PCB support(4-5-15) STUD PCB 받침(4-5-15) 4(Ass’y)
