28
Tyco Solarlok plug-in connection system
The Solarlok plug-in connection system is
used for the simple, reliable connection
of individual solar generators up to the
solar inverter.
Components
The following connectors are used:
· Positively coded connector
· Negatively coded connector
· Neutral connector
The neutral connector can be used to
connect both positively and negatively
coded sockets.
Installation
Extreme danger from electric shock!
Touching live parts can result in death.
All electrical work must be conducted by
a qualified electrician while observing
the VDE regulations, national and other
regulations!
Tyco Solarlok connectors are only reliable
for connection on permanently installed
lines.
Only the Tyco-Solarlok hand crimping pli
-
ers may be used to crimp the connectors.
