During preassembly, the connectors must
be separated from all other voltage
sources.
The connectors may not be separated
while under load. The circuit must be
opened at a suitable point for this pur
-
pose.
Provide the lines with corresponding
stickers as close as possible to the connec
-
tors to prevent confusion.
Any kind of soiling (dust, moisture, etc.)
has a negative effect on the connector
system with regard to function over the
intended period of use. This particularly
applies to the suitability for use of the
seals and the crimping of the contacts.
Therefore, extreme care must be taken
to achieve proper processing during as
-
sembly.
Various circular contacts are used for
different conductor cross-sections with
the Tyco Solarlok connectors. The correct
tool insert must be used in accordance
with this cross-section. The included Tyco
Solarlok connectors are equipped with
circular contacts for a cable cross-section
of 4 mm² to 6 mm².
The seals and clamping baskets used in
the preassembled connectors are ap
-
proved for cable sheath diameters from
4.5 mm to 6.9 mm. Special seals and
clamping baskets must be used for cables
with a sheath diameter greater than
6.9 mm.
The Tyco Solarlok hand crimping pliers
can be purchased from your sales partner.
