2-26
SMT IPMI User's Guide
3. To set the IP address using the IPv6 format, enter an IPv6 Address in the
eld. Enter a DNS Server IP and DUID (unit ID) in the boxes below.
4. Check this box to enable Virtual LAN support, and enter the VLAN ID in the
eld.
5. LAN Interface
This feature allows the user to select the port to be used for IPMI out-of-band
communication.
•The default setting is Failover, which will allow IPMI to be connected from either
the shared LAN port (LAN1/0) or the dedicated IPMI LAN port. Precedence is
given to the Dedicated LAN port over the shared LAN port.
•Select <Dedicated LAN> for IPMI to connect through the IPMI Dedicated LAN
port at all time.
•Select Shared LAN for IPMI to connect through the LAN port on the board.
6. RMCP Port
This feature allows the user to select the desired RMCP (Remote Mail Checking
Protocol) port based on his conguration. The default port is 623.
After entering all elds above, click <Save> to save the Network settings.
