SureShot AC320 - Main Components of Flexoshot (Non-Portion-Control); Figure 3: Main Exterior Components AC230-SS with Self-Serve Dispense Handles and Illuminated Display; Figure 4: Main Exterior Components AC330-SS with Low Touch Cup Levers and Illuminated Display

IntelliShot & FlexoShot: Operations Manual Page 2
MAIN COMPONENTS OF FLEXOSHOT (NON-PORTION-CONTROL)
1. Valve door
2. Side console (temp
display/adjustment)
3. Power switch
4. Circuit breaker
5. Illuminated door graphic
6. Product ID magnets
7. Thumbscrew on valve door
8. Self-serve dispense handles
9. Front panel
10. Catch tray
Figure 3: Main exterior components AC230-SS with self-serve dispense handles and illuminated display
Actual dispenser may not be exactly as shown.
Figure 4: Main exterior components AC330-SS with low touch cup levers and illuminated display
Actual dispenser may not be exactly as shown.
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
①
1. Low touch cup lever
