SPECIALS
Specials MJB4 Rev06 10-09 41
4
• Load the stamp on the stamp holder and adjust
it against the fixed pins
• Fix the stamp with vacuum by pressing the key
Stamp vac. is off
• Load the stamp holder into the mask holder
frame and fix it with the knurled knobs.
• Press next to confirm.
• If you start your process for the first time turn the
knob for the variable thickness setting down
(clockwise) to be within a save distance for
WEC.
• The program prompts the operator to load the
substrate without resist.
• The subsequent steps are
•WEC
• WEC pressure adjustment
