178 TimeSource 3100
TL1 Reference
097-72020-01 Issue 9: November 2003
Retrieve Performance Monitoring (cont’d)
Note: PHASE1S Data types:
• One 15 minute bin from the last 24 hours of data is displayed as 900 seconds of data.
To select a 15 minute bin, enter mondat and montm. Any mondat/montm
combination outside of the past 24 hour window is denied. Any time increment may
be entered. The system rounds the value to the nearest bin.
• Entered minutes of 1 to 15 correspond to the first 15 minute bin, 16 to 30 correspond
to the second 15 minute bin, etc.
• The first monitor value is the first second of the 900 second window.
• The 900 seconds of data is broken into 9 groups of 100 seconds. For each group of
100 seconds, the first value is the absolute 1 second phase for that group. The
absolute 1 second phase value is followed by 99 seconds of delta phase values.
