78 TimeSource 3100

Installation

097-72020-01 Issue 9: November 2003

SSSSSSSSSSS SSSS S SSSSS SSSS SSS S SSS S SSSSS S

Ethernet

Connect the Ethernet cable from the network to the 10base-T Ethernet connector labeled E-

NET. See Figure 13 for the connector location, and Table E for the connector pinouts.

Table E. Ethernet 10base-T RJ-45 Connector Pinouts

Pin Signal Abbreviation Direction

1 Transmit data + TXD + From TimeSource

3100

2 Transmit data – TXD – From TimeSource

3100

3 Receive data + RXD + To TimeSource 3100

4— — —

5— — —

6 Receive data – RXD – To TimeSource 3100

7— — —

8— — —
