TimeSource 3100 77

Installation

097-72020-01 Issue 9: November 2003

SSSSSSSSSSS SSSS S SSSSS SSSS SSS S SSS S SSSSS S

Figure 25. RJ-45 to DB-25 TOD Converter Connections

Table D. Converter DB-25 Connector Pinouts

Pin Signal

1 Frame ground

3 Data output (RS-232)

5 1 pps (RS-232)

7 Signal ground

Note: Pins not listed are reserved

for future use.
