TimeSource 3100 93
Installation
097-72020-01 Issue 9: November 2003
2
5
3
SSSSSSSSSSS SSSS S SSSSS SSSS SSS S SSS S SSSSS S
7 To select the high-speed download option, in which the firmware download
takes place at approximately 12 times the default speed of 9600 baud,
select the Use High Speed (115K baud) check-box, then click the Next>>
button to progress to the next screen.
If you do not wish to use the high-speed download option, leave the Use
High Speed (115K baud) check-box unselected and click the Next>>
button.
Note: In most cases, it is desirable to proceed with the Use High Speed
(115K baud) check-box selected. In certain instances, as when the PC’s
communications port does not support a 115K baud rate, de-select the Use
High Speed (115K baud) check-box before proceeding.
Procedure F. TimeWizard Installation and Operation (cont’d)
Step Procedure
