Chapter 1 General

1-4

Terms Definition Remarks

Sink Input

Current flows from the switch to the PLC input terminal if a input signal turns on.

Source

Input

Current flows from the PLC input terminal to the switch after a input signal turns

on.

Sink Output

Current flows from the load to the output terminal and the PLC output turn on.

Source

Output

Current flows from the output terminal to the load and the PLC output turn on.

Output

Contact

Output Contact
