Chapter 4 Names of Parts
4 -13
4.4 Communication I/F Module
4.4.1 Cnet I/F Module
1) G7L-CUEB
2) G7L-CUEC
4.4.2 Fnet I/F Module
1) G7L-FUEA
No. Names
① RS-232C connector
② Communication status LED
③ Expansion cable
④ Expansion cable connecting terminal
⑤ TM/TC selecting dip switch
No. Names
① RS-422/485 connector
② Power supply/Communication status LED
③ Expansion cable
④ Expansion cable connecting terminal
No. Names
① Station No. selecting switch
② Fnet cable connector 1 and 2
③ Expansion cable
④ Expansion cable connecting terminal
⑤ Communication status LED
