Appendix 2 Flag List

App2-8

(5) System error history(when RTC module is attached)

Rela

Description

D4900 Error pointer

D4901 Year, Month

D4902 Day, Time

D4903 Minute, Second

D4904 Error code

(6) Clock data

Relay Description

D4990 Year, Month

D4991 Day, Time

D4992 Minute, Second

D4993 Day of week, Century
