Chapter 4 Names of Parts

4 -12

4.3.4 Analog timer Module

No.

Names

①

RUN LED

②

Analog Timer Volume Control Resistor

③

Expansion Cable

④

Expansion Cable Connecting Terminal

4.3.5 RTD Input Module

No.

Names

①

RUN LED

②

Analog Timer Volume Control Resistor

③

Expansion Cable

④

Expansion Cable Connecting Terminal

①

②

③

④

③

①

④

②

⑤

②
