Chapter 4 Names of Parts
4 -10
4.3 Special Module
4.3.1 A/D·D/A Combination Module
1) G7F-ADHA
No.
Names
①
RUN LED
②
Analog Output Terminal
③
Analog Input (Voltage/current) selecting jumper pin
④
Analog Input Terminal
⑤
External Power Supply Terminal (DC24V)
⑥
Expansion Cable
⑦
Expansion Cable Connecting Terminal
2) G7F-ADHB
No.
Names
RUN LED
Analog Input Terminal
Analog Output Terminal
External Power Supply Terminal (DC24V)
Expansion Cable
Expansion Cable Connecting Terminal
⑦
①
②
③
④
⑤
⑥
①
③
④
②
⑤
⑥
