3) Mode change Remote operation
Remote operation mode change is available only when the operation mode is set to the remote STOP mode
(i.e., the mode setting switch position is in the STOP→ PAU/REM’).
Mode setting switch
position
Mode Change
Mode change by the
KGLWIN
Mode change using
FAM or Cnet I/F, etc.
Remote STOP Æ Remote RUN
○ ○
Remote STOP Æ Remote PAUSE X X
Remote STOP Æ DEBUG
○ ○
Remote RUN Æ Remote PAUSE
○ ○
Remote RUN Æ Remote STOP
○ ○
Remote RUN Æ DEBUG X X
Remote PAUSE Æ Remote RUN
○ ○
Remote PAUSE Æ Remote STOP
○ ○
Remote PAUSE Æ Remote DEBUG X X
DEBUG Æ Remote STOP
○ ○
DEBUG Æ Remote RUN X X
PAU / REM
DEBUG Æ Remote PAUSE X X
