Chapter 8 Communication Functions

8-75

• Dedicated modem and dial-up modem are both available and Set connection option of KGLWIN as below.

3) Remote connection by Fnet I/F module

• Remote connection by Fnet interface is available by setting connection option of KGLWIN as below

G7L-FUEA
