Chapter 4 Names of Parts

4 -9

4.2.3 8points I/O Module

1) G7E-DC08A

2) G7E-RY08A

No. Names

① Input LED

② Input contact

③ Input common terminal

④ Expansion cable

⑤ Expansion Cable Connecting Terminal

No. Names

① Output LED

② Output contact

③ Output common terminal

④ Expansion cable

⑤ Expansion Cable Connecting Terminal

①

②

③

②

③

⑤

④

①

②

③

②

③

⑤

④
