Chapter 2 System Configuration

2-3

(3) RS-232C Communication over a long distance via modem by Cnet I/F modules

2) 1:n Communications system

This method can connect between one computer and multiple main units for up to 32 stations

Modem

G7L-CUEB

MASTER-K120S

RS-232C ⇔ RS-422 Converter

Can be connected Max. 32 stations

G7L-CUEC

MASTER-K120S

RS-232C ⇔ RS-485

Converter

Built-in RS-485 Built-in RS-485

Built-in RS-485

* Refer to ‘chapter 8. communication function’ for details.
