Chapter 8 Communication Functions

8-4

(3) 1:1 connection with other MASTER-K120S

MASTER-K120S

main unit

MASTER-K120S main unit

Pin no.

Pin assignment and direction

Pin no. Signal

1 1 5V

2 2 RXD1

3 3 TXD1

4 4 RXD2

5 5 SG

6 6 5V

7 7 TXD2

8 8 SG

9 SG

MASTER-K120S main unit Connection method and signal direction

MASTER-K120S main unit

485+

485-

RS-232C interface

Male Type

MASTER-K120S main unit

RS-485 interface
