T-solution MASTER-K120S User Manual

Chapter 8 Communication Functions
8-37
(2) Program
(2) Parameter setting for slave station.
① Set parameters as the following table.
Communication Method
Protocol
and mode
Commu-
nication
Station no. Baud rate Data bit Parity bit Stop bit Communication channel Timeout Dedicated
Enable 31 19200 8 None 1
RS232C null modem or
RS422/485
- slave
② Slave station does not need program.
③ Baud rate, parity bit, data bit, stop bit setting must be same with master station.
