T-solution MASTER-K120S - Page 42

Chapter 5 Power Supply / CPU
5-5
(continued)
Specifications
Items
K7M-DR10UE K7M-DR14UE K7M-DR20UE K7M-DR30UE
Remarks
Cnet I/F Function
Dedicated protocol support
MODBUS protocol support RS-232C - 1port
User defined protocol support RS-485 - 1 port
No protocol support
RS-485 is available
on K7M-DR10/14UE
only
Capacity
1 phase : 10 kHz-2 channel
2 phase : 5 kHz-1 channel
Counter
function
4 different counter modes as following;
-. 1 phase operation mode.
-. 2 phase CW/CCW mode.
-. 1 phase Pulse + Direction mode.
-. 2 phase Multiplication mode(MUL4)
High-speed
counter
Additional
function
Internal/External preset function
Latch Counter function
RPM function
Comparison Output function
Pulse catch
Minimum pulse width : 50 ㎲(4 points)
External interrupt
50 ㎲(4 points)
Built-in
Function
Input filter 0 ~ 1000ms(Adjustable)
Weight (g) 360 370 500 510
