Table 4.2
AR 2000 Rheometer Specifications
Angular Displacement 40 nRad
Resolution
Minimum Strain 0.00006
Normal Force Range 1 g to 5000 g
Table 4.3
Peltier Plate System Specifications
Temperature Range
tank & pump -5°C to 100°C
pumped water supply (20°C) -20°C to 200°C
water at 60°C 10°C to 200°C
water at 40°C 0°C to 200°C
water at 1°C -30°C to 180°C
fluid at -20°C -40°C to 160°C
Typical Ramp Rate 30 °C min
-1
Ramp Rate (20 to 100 °C) 50 °C min
-1
(100 to 150 °C) 25 °C min
-1
Pt100 Internal Resolution 0.01 °C
Table 4.4
Optional Accessory Specifications for
Environmental Test Chamber Module (ETC)
Temperature Range
No cooling 50°C to 600°C
LN2 cooling -150°C to 600°C
Typical Ramp Rate maximum ramp rate 25°C/min
Internal Resolution 0.02 °C
