2.4 Specifications.
2.4.1 TPR-720A Specification.
TPR-720A
The Column diameter 210mm
Distance from the column surface to the spindle center,
max
750mm
Distance from the column surface to the spindle center,
min
220mm
Horizontal travel of the Spindle head. 530mm
Distance from the Base surface to the Spindle end, max. 1060mm
Distance from the Base surface to the Spindle end, min. 260mm
Elevating height of the Arm. 580mm
Effective area of the Box Table. 600mm╳
╳╳
╳445mm╳
╳╳
╳380mm
The dimensions of the Base (L ╳
╳╳
╳ W ╳
╳╳
╳ H) 1250mm╳
╳╳
╳640mm╳
╳╳
╳160mm
Taper hole of the Spindle. MT#4
Stroke of the Spindle. 220mm
R.P.M. of the Spindle.（
（（
（rounds╱
╱╱
╱min.╳
╳╳
╳ step）
））
） 88,154,282,455,796,1500six steps
Feed rate of the Spindle（
（（
（MM╱
╱╱
╱round╳
╳╳
╳speed）
））
） 0.05,0.09,0.15 3 speeds.
Horse Power of the main motor. 1.5KW(2HP)
Horse Power of the elevating motor. 0.75KW(1HP)
Horse Power of the cooling pump motor. 0.1KW(1/8HP)
The machine height from floor, max. 2170mm
Height from the Column top to floor 1850mm
Net weight (approx.) kgs 1120kg
Shipping Gross weight. (approx.) kgs 1250kg
Shipping dimensions(L╳
╳╳
╳W╳
╳╳
╳H) 1625mm╳
╳╳
╳810mm╳
╳╳
╳2160mm
The max. processing capacity.
Steel ∅
∅∅
∅32
Drilling
Cast iron ∅
∅∅
∅50
Steel ∅
∅∅
∅25
Tapping
Cast Iron ∅
∅∅
∅32
