2.4.4 TPR-1100 specification.
TPR-1100
The Column diameter 260mm
Distance from the Column surface to the Spindle center, max.
1100mm
Distance from the Column surface to the Spindle center, min.
280mm
Horizontal travel of the Spindle head. 820mm
Distance from the Base surface to the Spindle end, max. 1270mm
Distance from the Base surface to the Spindle end, min. 470mm
Elevating height of the Arm. 570mm
Effective area of the Box Table. 635mm╳
╳╳
╳520mm╳
╳╳
╳415mm
The dimensions of the Base (L ╳
╳╳
╳ W ╳
╳╳
╳ H) 1710mm╳
╳╳
╳715mm╳
╳╳
╳180mm
Taper hole of the Spindle. MT#4
Stroke of the Spindle. 230mm
R.P.M. of the Spindle.（
（（
（rounds╱
╱╱
╱min.╳
╳╳
╳ step）
））
） 44-1500 12 steps
Feed rate of the Spindle（
（（
（MM╱
╱╱
╱round╳
╳╳
╳speed）
））
） 0.05,0.09,0.153 3 speeds
Horse Power of the main motor. 2.25KW(3HP)
Horse Power of the elevating motor. 0.75KW(1HP)
Horse Power of the cooling pump motor. 0.1KW(1/8HP)
The machine height from floor, max. 2530mm
Height from the Column top to floor 2000mm
Net weight (approx.) kgs 1800 kg
Shipping Gross weight. (approx.) kgs 1950 kg
Shipping dimensions(L╳
╳╳
╳W╳
╳╳
╳H) 1880mm╳
╳╳
╳870mm╳
╳╳
╳2210mm
The max. processing capacity.
Steel ∅
∅∅
∅42
Drilling
Cast iron ∅
∅∅
∅55
Steel ∅
∅∅
∅25
Tapping
Cast Iron ∅
∅∅
∅38
