Tailift TPR720A - Rotate the Arm Right or Leftwards

5-21
5.9 Rotate the arm right or leftwards.
(For TPR-720A, TPR-820A, TPR-920A) (For TPR-1100)
Steps Description
1. Push the head lever downwards to release, as shown in picture 1.
2.
Rotate the hand wheel clockwise to move rightwards and counter clockwise to move
leftwards, as shown in picture 2.
3. Pull the head lever upwards to tighten the head, as shown in picture 1.
