7-7
7.4 Maintenance and replacement period.
No.
Position Items. Period
1. Oil filler points of the column CC68 once per day.
2. Oil filler points on top of the gearbox CC68 once per day.
3. Oil filler points in the right side of the gearbox. CC68 once per day.
4. Oil filler points in the left side of the gearbox. CC68 once per day.
5. Oil filler points of the spindle XM2 once per day.
6 Replace oil for the speed reduction of the arm
elevating motor.
CC68 once per year.
7 Change oil inside of the gearbox. CC68 once per year.
8 Chang the cutting fluids. The cutting fluids once per
month.
9 The arm transmit ion ball screw XM2 Once per
month
A suitable Oil Type comparison:
ISO DIS-3498
SHELL MOBIL ESSO CHINA
CC68
OMALA 68
MOBILGEAR 620 SPARTAN EP68 HD68
XM2
ALVANIA R2 MOBILUX 2 BEACON 2 #2
7.5 Waste disposition.
Please proceed waste disposition such as machine oil, iron filings, old machine or replaced
parts according to your country’s relevant legal regulation.
