Tailift TPR720A - TPR-820 A Specification

2-5
2.4.2 TPR-820A Specification.
TPR-820A
The Column diameter 210mm
Distance from the column surface to the spindle center, max
850mm
Distance from the column surface to the spindle center, min
220mm
Horizontal travel of the Spindle head. 630mm
Distance from the Base surface to the Spindle end, max. 1210mm
Distance from the Base surface to the Spindle end, min. 350mm
Elevating height of the Arm. 640mm
Effective area of the Box Table. 600mm╳
╳╳
╳445mm╳
╳╳
╳380mm
The dimensions of the Base (L ╳
╳╳
╳ W ╳
╳╳
╳ H) 1250mm╳
╳╳
╳640mm╳
╳╳
╳160mm
Taper hole of the Spindle. MT#4
Stroke of the Spindle. 220mm
R.P.M. of the Spindle.（
（（
（rounds╱
╱╱
╱min.╳
╳╳
╳ step）
））
） 88,154,282,455,796,1500 6 steps
Feed rate of the Spindle（
（（
（MM╱
╱╱
╱round╳
╳╳
╳speed）
））
） 0.05,0.09,0.15 3 speeds
Horse Power of the main motor. 1.5KW(2HP)
Horse Power of the elevating motor. 0.75KW(1HP)
Horse Power of the cooling pump motor. 0.1KW(1/8HP)
The machine height from floor, max. 2320mm
Height from the Column top to floor 2010mm
Net weight (approx.)kgs 1200 kg
Shipping Gross weight. (approx.)kgs 1340 kg
Shipping dimensions(L╳
╳╳
╳W╳
╳╳
╳H) 1680mm╳
╳╳
╳810mm╳
╳╳
╳2210mm
The max. processing capacity.
Steel ∅
∅∅
∅32
Drilling
Cast iron ∅
∅∅
∅50
Steel ∅
∅∅
∅25
Tapping
Cast Iron ∅
∅∅
∅32
