3-5
3.4.2 For TPR-1100
M
otor Part Name Rated Power Capacity Maximum Initiate Power
Main Motor 2.25kw 6.3kw
Elevating Motor 0.75kw 2.1kw
Coolant Pump Motor 0.1kw 0.28kw
Total Rated Power Capacity:
(1.5kw+0.75kw+0.1kw)=3.1kw………………….. (1)
Maximum Total Initiate Power Capacity:
(4.2kw+2.1kw+0.28kw)=8.68kw…………………..(2)
Transformer Rated Output Power Capacity for Control Circuits
Model
Item 100VA
Input
AC400V±
±±
±10% 1∅
∅∅
∅
Power Supply
Output
AC240V±
±±
±10% 1∅
∅∅
∅
Ambient Temperature 0°C To 55°C
S=KVA
P=KW
Pf ×
××
×n = 0.75 (Correction Factors)
S=
KW
Pf×
××
×n(0.75)
P=
3.1Kw
0.75
=4.133KVA………………………(1)
P=
8.68Kw
0.75
=11.573KVA……………………(2)
Power Equipment Capacity=
4.133KVA+11.573KVA
2
=7.853KVA
