9-7
9.7 Eletrical main parts list
(For TPR-720A, TPR-820A, TPR-920A Standard )
Part NO.
Symbol
Name Specification Q’ty
Remark
E0701006 M1 Magnetic Contact CN11 3a1b 110V 1 Standard
E0701006 M2 Magnetic Contact CN11 3a1b 110V 1 Standard
E0701006 M3 Magnetic Contact CN11 3a1b 110V 1 Standard
E0701006 M4 Magnetic Contact CN11 3a1b 110V 1 Standard
E0701006 M5 Magnetic Contact CN11 3a1b 110V 1 Standard
E0701006 M0 Magnetic Contact CN11 3a1b 110V 1 Standard
E3101010 FU Fuse E16 30A 3 For Asia
E3101013 FU Fuse E16 6A 1 For Asia
E1801005 TR Transformer PT40 1 Standard
E0207011 OL1 Overload Relay RH 18/7 1 For 220V~230V
E0207007
OL1 Overload Relay RH 18/4 1 For 380V~460V
E0207007
OL2 Overload Relay RH 18/4 1 For 220V~230V
E0207008
OL2 Overload Relay RH 18/1.7 1 For 380V~460V
E1618001 PB1 Emg.Push Button
Switch
SBT-307 1
Standard
E1304001
SS1 Selector Switch ST 251 1 Standard
E1604001
SS2 Selector Switch SN1021 1 Standard
E1605001
SS3 Cross Switch 3Joint.UP1A.Down1A
Left1A1B.Right1A1B
1
Option
E0901021 SS3 Limit Switch V-15-1E5 4 Standard
B100006 SS4 Push button ZB4-BA2+ZB4-BZ101
1 Standard
B100006 SS5 Push button ZB4-BA2+ZB4-BZ101
1 Standard
E0901021
LS1 Limit Switch V-15-1E5 1 Standard
E0901014
LS2 Limit Switch MJ2-1308 1 Standard
E0901014
LS3 Limit Switch MJ2-1308 1 Standard
E0901014
LS4 Limit Switch MJ2-1308 1 Standard
E1701002
WL Work Lamp FS51441 1 Standard
E2303002
PL Pilot Light SP-251 110V 1 Standard
E3602002
Amp Meter S065 20A 1
For 200V~230V
E3602003
Amp Meter S065 10A 1
For 380V~460V
Coolant Pump
Motor
1/8HP/2P/3PH
L:130mm
1
Standard
Main Motor Vertical 2HP/4P/3PH
1 Standard
Elevating Motor Horizontal
1HP/4P/3PH
1
Standard
