9-10
9.9 Eletrical main parts list
(For TPR1100 Standard )
Part NO. Symbol
Name Specification Q’ty
Remark
E0701006 M1 Magnetic Contact
CN11 3a1b 110V 1 Standard
E0701006 M4 Magnetic Contact
CN11 3a1b 110V 1 Standard
E0701006 M5 Magnetic Contact
CN11 3a1b 110V 1 Standard
E0701006 M0 Magnetic Contact
CN11 3a1b 110V 1 Standard
E0701007 M2 Magnetic Contact
CN18 110V 1 Standard
E0701007 M3 Magnetic Contact
CN18 110V 1 Standard
E3101009
FU Fuse Seat E-16 4
For Asia
E3101010
FU Fuse E 16 30A 3
For Asia
E3101013
FU Fuse E 16 6A 1
For Asia
E1801005 TR Transformer PT40 1 Standard
E0207010
OL1 Overload Relay RH 18/15 1
For 200V~230V
E0207011
OL1 Overload Relay RH 18/7 1
For 380V~460V
E0207007
OL2 Overload Relay RH 18/4 1
For 220V~230V
E0207008
OL2 Overload Relay RH 18/1.7 1
For 380V~460V
E1618001
PB1 Emg.Push Button
Switch
SBT-307 1
Standard
E1303001
SS1 Selector Switch ST 302 1
Standard
E1604001
SS2 Selector Switch SN1021 1
Standard
E1605001
SS3 Cross Switch
3 Joint UP1A Down1A
Left1A1B Right1A1B
1
Option
E0901021 SS3 Limit Switch V-15-1E5 4 Standard
E1603001
SS4 Pole Reversing
Switch
A441 CA10 1
Standard
B100006
SS5 Push button ZB4-BA2+ZB4-BZ101
1
Standard
B100006
SS6 Push button ZB4-BA2+ZB4-BZ101
1
Standard
E0901006
LS1 Limit Switch MJ2-1308R 1
Standard
E0901014
LS2 Limit Switch MJ2-1308 1 Standard
E0901014
LS3 Limit Switch MJ2-1308 1 Standard
E0901034
LS4 Limit Switch AZ 7311 1 Standard
E1701002
WL Work Lamp FS51441 1 Standard
E2303003
PL Pilot Light SP-301 110V(R) 1 Standard
E2303004
PL Pilot Light SP-301 110V(W) 1 Standard
E3602001
Amp Meter S065 30A 1
For 200V~230V
E3602002 Amp Meter S065 20A 1
For 380V~460V
