136 Disassembly and Reassembly TM9100 Service Manual
© Tait Electronics Limited August 2005
7. Unscrew the four screws E and remove the control-head board F.
8. Pull the concealed microphone
1% capsule out of its rubber seal when
removing the control head-board
F. If necessary, unsolder the leads
from the pads on the control-head board (refer to Figure 5.8).
9. Remove the light pipes
H and I.
10. The space-frame
J clips into three clips of the front panel.
Unclip the spaceframe and remove it along with the two seals
G.
Check the seals
G and replace them, if necessary.
11. Remove the speaker
1! and speaker clamp 1).
Important When fitting the speaker and the speaker clamp, observe the
orientation of the speaker terminals. Make sure that the
larger of the three legs of the speaker clamp is placed
between the two clips of the front panel assembly as shown
in Figure 5.8 on page 135.
12. Remove the LCD assembly
1@, main keypad 1#, and power keypad
1$.
