TM9100 Service Manual Transmitter Fault Finding (50W/40W Radios) 289
© Tait Electronics Limited August 2005
Figure 11.19 Components of concern on the bottom-side of the main board (H5 and H7 bands)
H5, H7 BANDS
C319
R341
R340
R396
COPPER PLATE
VCO BOT CAN
