TM9100 Service Manual Transmitter Fault Finding (50W/40W Radios) 311
© Tait Electronics Limited August 2005
Figure 11.28 Components of concern on the bottom-side of the main board (B1 band)
B1 BAND
R389
R390
NB BOT CAN
COPPER PLATE
VCO BOT CAN
