330 Transmitter Fault Finding (25W Radios) TM9100 Service Manual
© Tait Electronics Limited August 2005
Figure 12.6 PA circuitry under the
PAF TOP can and part of the directional coupler under the DIRC TOP
can (B1 band)
Mounting point
for test capacitor
Test pad
Temperature
sensor
