386 CODEC and Audio Fault Finding TM9100 Service Manual
© Tait Electronics Limited August 2005
Figure 13.7 Circuitry under the
CDC BOT can
LO2 BOT CAN
CAN FOR DIGITAL BOARD
JUNCTION
OF R224
AND IC204
