Tait TM9100 Service Manual

Ref. IPN Description
Ref. IPN Description
Ref. PCB Circuit Ref. PCB Circuit
Ref. PCB Circuit
TM9100 Service Manual Installing an Enhanced Remote Kit 471
© Tait Electronics Limited August 2005
R612 038-14470-00 Res 0603 4k7 1/16w +-5%
R701 038-16120-00 Res 0603 120k 1/16w +-5%
R710 036-13100-00 Res M/F SMD 0805 100e 5%
R720 038-15100-00 Res 0603 10k 1/16w +-5%
R721 038-14220-00 Res 0603 2k2 1/16w +-5%
R722 038-14470-00 Res 0603 4k7 1/16w +-5%
R730 038-12470-00 Res 0603 47e 1/16w ± 5%
R731 038-12470-00 Res 0603 47e 1/16w ± 5%
U300 002-12523-17 IC LM317l Reg T0252 0.5a
U310 002-14931-00 IC L4931CD33 3.3v 250Ma Regso8
U400 002-19120-00 IC TS912ID Cmos R2R Opamp
U500 002-13483-00 IC XCVR RS485 LTD SLEW RATE 3V
U600 002-15595-00 IC 74AHC595 8bit Shiftreg Tsop
U610 002-10126-71 IC SMD DS1868 Dgtl Pot Tsop20
U700 002-13001-00 IC TPA3001 20W Mono PA TSSOP24
220-01721-02 PCB MFX Head Remote
219-02914-00 Loom MFX Remote Head
302-10062-00 Brkt Remote Head TM8200
302-05263-00 Brkt U Thumb Scrw TMA
316-06842-00 Pnl Rear TM8200 MF2
346-10030-08 Scrw P/T Wn1412 Kc30x08 Zbc
349-00060-00 Scrw 10GX20 SLFDRL Hex/Poz TMA
353-05007-00 Wshr Rubber M4*19*1.0 S/A
354-01052-00 Fsnr Bush PSM SHK-B-M4 Ins
TMAA-4-01 Remote Cable Parts
219-02918-00 Cbl Rmt Ctrl Hd Kit, comprising:
240-02158-00 Conn Shld RJ45 Shortbody Plg
360-02022-00 Grommet Mic TMA
Grid Reference List
C100 J3 1E3
C101 K4 1E3
C102 J4 1E3
C103 J4 1E3
C110 L4 1F4
C300 M5 1G2
C301 N5 1F3
C310 M2 1G4
C311 M2 1G4
C320 P4 1D8
C400 L3 1G10
C401 L3 1G10
C410 M3 1G8
C411 M3 1G8
C420 L3 1G5
C421 L3 1G6
C422 K3 1F7
C423 K3 1F7
C430 M2 1G9
C500 L4 1F6
C600 L2 1C3
C601 L2 1B2
C610 K1 1C5
C611 K1 1C4
C612 J2 1C5
C700 F2 1C6
C701 G3 1C7
C702 F3 1C7
C703 E2 1C6
C704 G2 1C6
C705 G2 1B6
C706 E3 1B6
C707 E2 1B6
C708 G2 1A6
C710 E2 1D6
C711 F2 1D7
C712 E2 1D7
C730 E3 1B8
C731 G3 1A8
C732 F4 1B9
C733 G4 1B9
C734 F4 1B9
C735 F4 1B9
D100 K3 1E4 1F4
D101 K4 1F4 1E4
D102 K4 1F4 1E4
D103 K4 1E5 1F5
D104 K5 1E5
D110 L5 1F3
D201 K5 1E8
D211 K5 1C9
D300 N5 1G3
D301 M5 1G2
D720 G1 1D2
D730 F3 1B7
D731 G3 1B7
E100 J5 1E2
E101 H5 1E2
E102 K4 1F3
E103 K4 1E4
E105 H5 1F2
E710 F2 1D7
E711 F2 1D7
E730 E4 1B8
E731 G4 1B8
J100 H4 1E1
J200 P3 1E10
J201 B4 1C10
L712 D2 1D8
L730 E4 1B9
L731 G4 1B9
MT800 D3 1A4
MT801 M3 1A5
Q610 K1 1D4
Q720 F1 1D2
Q721 G2 1D3
R100 J3 1F2
R110 L4 1F3
R200 N4 1F8
R201 R3 1E8
R202 R2 1E8
R210 C3 1D9
R211 B3 1C9
R212 B4 1C9
R300 N5 1G3
R301 N5 1G3
R320 N4 1E8
R321 M4 1E8
R401 L3 1G10
R402 L3 1G10
R410 M3 1G8
R411 M3 1G7
R412 L4 1G7
R420 L3 1G6
R421 L3 1G6
R422 K3 1F7
R430 M2 1G9
R431 M2 1G9
R440 K3 1E5
R441 K3 1D5
R442 J3 1D5
R501 M4 1E7
R510 K4 1F6
R511 K4 1F5
R600 L2 1B1
R601 L2 1B2
R602 L1 1C1
R603 L2 1C1
R604 L2 1B1
R605 L2 1B3
R606 M2 1B3
R607 M2 1B3
R608 M2 1B3
R609 M2 1B4
R610 J2 1B5
R611 K1 1C4
R612 K1 1D4
R701 E3 1B6
R710 F2 1D6
R720 F1 1D1
R721 F1 1D2
R722 G1 1D2
R730 E3 1B7
R731 G3 1A7
U300 P5 1G3
U310 N2 1G4
U400 L3 1F6 1G9 1G7
U500 L4 1F7
U600 L2 1B2
U610 K2 1B4
U611 K2 1A3
U700 F3 1B7
