Takeuchi TB 250 - Page 254

4-149
4
TRAVEL MOTOR
DISASSEMBLY AND ASSEMBLY
9. Install the O-rings (large and small) on the valve body.
10. Press fit the oil seal in the flange holder.
• Do not disassemble the oil seal unless necessary.
Add grease between the lips of the oil seal.
11. Install the pin.
12. Install the 2nd speed piston.




