ALGORITHMS
M5ALGOIN
Rev 1.7 Page 29
HICUT-1 500 Hz - flat High cut filter for channel 1. Enables
you to make the pitch-transposer more
"warm". This is a 6 dB per octave filter.
ATT-1 -40 - 0.0 dB Gain for HICUT filter. Adjusts in 0.5 dB
steps.
HICUT-2 500 Hz - flat High cut filter for channel 2 Enables you
to make the pitch-transposer more
"warm". This is a 6 dB per octave filter.
ATT-2 -40 - 0.0 dB Gain for HICUT filter. Adjusts in 0.5 dB
steps.
PAGE 5:
FB-1 0 - 100 The percentage of feedback for channel 1
(feedback path includes delay, pitch and
hi-cut).
FB-2 0 - 100 The percentage of feedback for channel 2
(feedback path includes delay, pitch and
hi-cut).
XFB 1>2 0 - 100 The percentage of crossfeed from
channel 1's output to ch. 2's input.
XFB 2>1 0 - 100 The percentage of crossfeed from
channel 2's output to ch. 1's input.
PAGE 6:
DELAY-1 0 - 310 mS The delay setting for channel 1.
DELAY-2 0 - 310 mS The delay setting for channel 2.
PAGE 7:
DGSPEED 0.05 - 0.5 The deglitch speed parameter should be
set relatively low for slowly changing
and monophonic source material. Higher
settings are for fast changing and
polyphonic material.
POLYSPD 5 - 50 The polyphonic speed parameter should
be set high for polyphonic and bass type
sources.
POLYDLY 5 - 18 The polyphonic delay parameter controls
the response to polyphonic signals.
When this parameter is turned up the
response time will be slower, but the
