3
No.
Control/Indicator
Description
10 PROG Button / Indicator Activates the Program / Sequencer menu.
The Program menu provides Sequencer function control, Trigger function
control, and loads a sequence stored inside the power supply memory.
Green LED lights when Program menu is active. If Program menu is active,
press PROG button to exit to the main display. *
11 SYST / Lock Front Panel
Button / Indicator
Activates the System menu.
The System menu provides output sensing point selection (Local / Remote
sense), Interlock function control, Enable function control, Power Supply OK
signal control, SAVE/RECALL power supply configuration, Programmable
Signals control, Preload function control, Display brightness & dimming
function control, and reset power supply settings.
Green LED lights when System menu is active.
If System menu is active, press the SYST button to exit to the main menu.
Lock / Unlock Front Panel buttons by pressing the SYST button, followed by
current encoder press. *
12 CONF Button / Indicator Activates the Configuration menu.
The Configuration menu provides power supply start mode control, Voltage
& Current source control, Analog Programming / Monitoring range selection,
Internal Resistance function, Constant power limit function, and Slew-Rate
control function.
Green LED lights when the Configuration menu is active.
If Configuration menu is active, press the CONF button to exit to the main
menu. *
13 PROT Button / Indicator Activates the Protection menu.
The Protection menu provides OVP setting, UVL setting, UVP function
control, Foldback function control, and OCL function ON/OFF control.
Green LED lights when the Protection menu is active.
If Protection menu is active, press the PROT button to exit to the main
menu. *
