TDK-Lambda GH10-100 - Page 53

42
Function
Factory Reset
(Default Settings)
Reset
Last
Setting
Save & Recall
Power Supply Start Mode
SAFE
SAFE
+
+
Power Supply Output State
OFF
OFF
+
OFF
Voltage Set Point [V]
0
0
+
+
Current Set Point [A]
1.05 * RATED
0
+
+
Over Voltage Protection (OVP) [V] 1.1 * RATED
or 1.2 * RATED
(Model Dependent)
1.1 * RATED
or 1.2 * RATED
(Model Dependent)
+ +
Under Voltage Level (UVL) [V]
0
0
+
+
Under Voltage Protection (UVP) Mode
OFF
OFF
+
+
Under Voltage Protection (UVP) Delay [S]
01.0
01.0
+
+
Fold-Back Mode
OFF
OFF
+
+
Fold-Back Delay [S]
01.0
01.0
+
+
Constant Power Function
OFF
OFF
+
+
Constant Power Set Point [W] RATED VOLTAGE
MULTIPLYED BY
RATED CURRENT
RATED VOLTAGE
MULTIPLYED BY
RATED CURRENT
+ +
Slew Mode
OFF
OFF
+
-
Voltage Slew Up / Down [V/mS]
999.99
999.99
+
-
Current Slew Up / Down [A/mS]
999.99
999.99
+
-
Internal Resistance Function
OFF
OFF
+
+
Internal Resistance Set Point [Ω]
0.001
0.001
+
+
Voltage Reference Programming Source
DIG
-
+
-
Current Reference Programming Source
DIG
-
+
-
Analog Mode Current Limit (OCL)
OFF
-
+
-
Analog Programming & Monitoring Range [V]
5
-
+
-
Programmable Pin 1
OFF
OFF
+
+
Programmable Pin 2
OFF
OFF
+
+
Front Panel Remote Mode
LOCAL
REM
+ *1
-
Front Panel LOCK
OFF
-
+
-
Output Sense (LOC / REM)
LOC
-
+
-
Interlock (ILC) Function
OFF
-
+
-
Enable (ENA) Function
OFF
-
+
-
Enable (ENA) Polarity
REV
-
+
-
Power Supply OK (PS_OK) Delay [S]
00.01
-
+
-
Preload
ON
-
+
-
Communication Interface
User-Selectable *2
-
+
-
Communication Power Supply Address
06
-
+
-
Communication Baud Rate [Baud]
115200
-
+
-
Communication Language
SCPI
-
+
-
