87
MP?
Query
Returns the measured output power
Returns
<NR2> 5 digits format
DVC?
Query Displays Voltage and Current data. Data returns as a string of ASCII characters.
A comma separates different fields. Fields order: Measured Voltage, Programmed
Voltage, Measured Current, Programmed Current, Over Voltage Set Point and
Under Voltage Set Point
Example
10.000, 10.000, 020.02, 010.00, 040.5, 000.0
OUT <Bool>
Function Enable / Disable power supply output. OUT ON will respond with ‘E07’ if the
output cannot be turned on because of a latching fault (OTP, AC, ENA, ILC,
POFF, SO) shutdown
Parameters
0|1, OFF|ON
Query
OUT?
Returns
<Bool> 0|1
FLD <DSC>
Function Sets the Foldback protection to OFF, CC or CV mode. “FLD 0/OFF” deactivates
Foldback protection. “FLD 1/CC” arms CC Foldback protection. “FLD 2/CV” arms
CV Foldback protection
Parameters
0|1|2 or OFF|CC|CV
Query
FLD?
Returns
<DSC> OFF|CC|CV
FBD <NR1>
Function
Sets the delay time from Foldback fault event to output disable
Parameters
1-255 (1=0.1sec). Value rounded to 0.1 resolution
Query
FBD?
Returns
<NR1>
FBDRST
Function
Reset the added Fold Back Delay to default
