Team Blacksheep CROSSFIRE - Receiver Output Mapping



Receiver functions
Output map
On all receivers you can select what it should output on which pin. The available options for each differ for
the receivers:
Receiver pin
Output type Diversity RX (standard)
Default value
1
PWM Ch1 bis 12, PPM, RSSI, LQ, RSSI/LQ
PWM Ch. 1
2
PWM Ch1 bis 12, PPM, RSSI, LQ, RSSI/LQ
PWM Ch. 2
3
PWM Ch1 to 12, RSSI, LQ, RSSI/LQ, SBUS, n.i.SBUS, Serial
TX, MAVLink TX, CRSF TX, SmartAudio
PWM Ch. 3
4
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ, Serial RX, MAVLink RX,
CRSF RX
PWM Ch. 4
5
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ
PWM Ch. 5
6
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ, Serial RTS
PWM Ch. 6
7
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ, Serial RX, MAVLink RX,
CRSF RX
PWM Ch. 7
8
PWM Ch1 to 12, RSSI, LQ, RSSI/LQ, SBUS, n.i.SBUS, Serial
TX, MAVLink TX, CRSF TX, DSMX, SmartAudio
PWM Ch. 8


Receiver pin
Output type Diversity RX (Nano)
Default value
1
PWM Ch1 bis 12, PPM, RSSI, LQ, RSSI/LQ, CRSF TX
PWM Ch. 1
2
PWM Ch1 bis 12, PPM, RSSI, LQ, RSSI/LQ, CRSF RX
PWM Ch. 2
3
PWM Ch1 to 12, RSSI, LQ, RSSI/LQ, SBUS, n.i.SBUS, Serial
TX, MAVLink TX, CRSF TX, DSMX, SmartAudio
PWM Ch. 3
4
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ, Serial RX, MAVLink
RX, CRSF RX
PWM Ch. 4
5
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ, Serial RTS
PWM Ch. 5
6
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ, Serial RTS
PWM Ch. 6
7
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ, Serial RX, MAVLink
RX, CRSF RX
PWM Ch. 7
8
PWM Ch1 to 12, RSSI, LQ, RSSI/LQ, SBUS, n.i.SBUS, Serial
TX, MAVLink TX, CRSF TX, DSMX, SmartAudio
PWM Ch. 8


