TBS CLOUD
All the TBS Crossfire transmitters* and the Fusion video receiver includes a built-in WiFi module which
allows you a connection with all your gear through the TBS Cloud. This allows for features like VTx
follow**, dynamic VTx power** and other upcoming features.
Note: at the moment all the Cloud features require a hotspot with internet access.
*if you own a Standard Tx from 2015/2016, the WiFI module in the JR adapter is missing. You can replace
the adapter with a new one from TBS.
**TBS Fusion video receiver required
Menu
● WiFi Client
○ AP Mode: enables/ disabled the WiFI module
○ Default SSID: enables/ disables the SSID broadcast
○ SSID: SSID/ name of the connected/ selected network
○ Password: enter the password for the network
○ Connect: manually connect to the network. Only necessary when a new network is chosen
under  SSID
○ Scan:  scans for WiFI networks. Found networks can be chosen under  SSID , manual
reconnect by  Connect  is required
○ Forget WiFi: erases all saved networks and there password
○ Upgrade: starts the self update for the WiFI firmware. Disabled at the moment
● UDP
○ MAVLink: enables/ disables the sending of MAVlink data over the wifi
○ Port: change the UDP port where the telemetry will be send
● WebUI
○ Login: enables/ disables the login with or without a password
○ Password: set up a password for the WebUI login
● About
○ WiFi: name of the network your Crossfire is connected to
○ IP: IP address the module got
○ Server: connection status
○ Firmware: version number of the WiFI firmware
○ Hardware: hardware revision of the WiFI module
○ Bootloader: version number of the Bootloader firmware


