Team Blacksheep CROSSFIRE - OpenTX Sensor Integration



Available sensors with OpenTX
With a OpenTX based radio you can receive the following sensors, depending on your connected
hardware:
Datapoint
Description
Data source
1RSS
Uplink - received signal strength antenna 1 (RSSI)
TBS CROSSFIRE RX
2RSS
Uplink - received signal strength antenna 2 (RSSI)
TBS CROSSFIRE RX
RQly
Uplink - link quality (valid packets)
TBS CROSSFIRE RX
RSNR
Uplink - signal-to-noise ratio
TBS CROSSFIRE RX
RFMD
Uplink - update rate, 0 = 4Hz, 1 = 50Hz, 2 = 150Hz
TBS CROSSFIRE RX
TPWR
Uplink - transmitting power
TBS CROSSFIRE TX
TRSS
Downlink - signal strength antenna
TBS CROSSFIRE TX
TQly
Downlink - link quality (valid packets)
TBS CROSSFIRE TX
TSNR
Downlink - signal-to-noise ratio
TBS CROSSFIRE TX
ANT
Sensor for debugging only
TBS CROSSFIRE TX
GPS
GPS Coordinates
TBS GPS / FC
Alt
GPS Altitudes
TBS GPS / FC
Sats
GPS Satellites acquired
TBS GPS / FC
Hdg
Magnetic orientation
TBS GPS / FC
RxBt
Battery voltage
TBS GPS / FC/ Crossfire Rx/ Core
Curr
Current draw
TBS GPS / FC/ Crossfire Rx/ Core
Capa
Current consumption
TBS GPS / FC/ Crossfire Rx/ Core
Ptch
FC Pitch angle
TBS GPS / FC
Roll
FC Roll angle
TBS GPS / FC
Yaw
FC Yaw angle
TBS GPS / FC
FM
Flight mode
TBS GPS / FC
* Source: FC means all FC’s with MAVLink or CRSF connection. Core means Core Pro, FPVision, Unify Evo
Missing sensors
If you got issues finding sensors or only a few appear, make sure you disabled Ignore Instances in the
telemetry settings page of your radio


