Long Range Two-Way Remote Control System
Europe: 868 MHz SRD Band
America: 915 MHz ISM Band
RF power
Radio Signal &
Telemetry downlink:
Micro TX V1: Selectable 25mW to 250mW
Micro TX V2: Selectable 25mW to 1W
Standard/ Lite TX: Selectable 10mW to 2W
Diversity, Micro and Nano RX: 40mW
TX: 1x omnidirectional dipole antenna
RX: depends on the receiver type (U.fl or SMA)
8 (Diversity/ nano Diversity)/ 4(6) (Micro/Nano RX) PWM (freely mappable )
or up to 12-channel PPM stream outputs, standard 2.54mm servo
connectors
Any radio with PPM stream output (Standard/ Lite Tx only)
Any radio with JR-style bay. OpenTX recommended
Micro TX: RGB LED light, push button, configuration via CRSF (TBS TANGO,
OpenTX ect. ), WiFi
Standard TX: 1.3-inch OLED display and joystick for configuration, binding
and link stats, Bluetooth, WiFi
(Nano) Diversity RX: Beacon-mode, receiver backup LiPo battery - operating
time of approx. 2 days
Pre-set servo positions or stops outputting servo pulse - selectable in
configuration menu or via push button
TX: Standard SMA, Standard Diversity rx: RP-SMA, U.fl (Micro/ Nano receiver)
Variable depending on output power and radio environment
TX: +3.5 to 12.6V via RC or HT 3-pin input connector, External 2S to 3S LiPo
via XT30 connector (standard RX only)
Diversity RX: +4.5V to 8.4V
Nano Rx’s: +4.5V to 8.4V (down to 3.3V possible, but not recommended)
All reverse-polarity protected, compatible for 2s Lipo direct
TX: 1.1W, at 25mW
TX: 3.2W, at 2000mW
Diversity RX: 1.5W / Micro/Nano RX: 1W
Diversity RX: 1x BST (the CROSSFIRE RX does not power the BST line), 8x
Servo connectors
Micro RX: V1: 1x Servo, 1x BST / V2: 4x Servo, 1x BST -
Nano RX: 2x Pin-headers for 1x BST and 4x Servo
Nano Div. Rx: 2x Pin-headers for 1x BST and 8x Servo
Standard TX: 150 x 80 x 20 mm, Micro TX: 73 x 56 x 35 mm
Diversity RX: 30 x 50 x 12 mm, Micro RX: 40 x 14 x 9.5mm
Micro TX: 38g, Standard TX: 340g,
Diversity RX: 25 grams, Micro RX: 3.2 grams
