TechnipFMC Sening MultiLevel User Manual


Sensor circuits: In intrinsically safe level of protection: II 2 G EEx ia
IIB with following maximum values:
U
O
= 16,8 V
I
O
= 240 mA
P
O
= 1,0 W
Characteristic: linear
Max. permissible external inductance
L
O
= 2,7 mH
Max. permissible external capacitance
C
O
= 2,29 µF
R55 circuits: In intrinsically safe level of protection: II 2 G EEx ia
IIB with following maximum values:
U
O
= 16,8 V
I
O
= 80 mA
P
O
= 340 mW
Characteristic: linear
Max. permissible external inductance
L
O
= 20 mH
Max. permissible external capacitance
C
O
= 2,29 µF
R56 circuits:
In intrinsically safe level of protection: II 2 G EEx ia
IIB with following maximum values:
UO = 16,8 V
IO = 2 mA
PO = 8 mW
Characteristic: linear
Max. permissible external inductance
LO = 1 H
Max. permissible external capacitance
CO = 2,29 µF
Level gauge sensor circuits: In intrinsically safe level of protection: II 2 G EEx ia
IIB with following maximum values:
U
O
= 16,8 V
I
O
= 179 mA
P
O
= 0,75 W
Characteristic: linear
Max. permissible external inductance
L
O
= 4,5 mH
Max. permissible external capacitance
C
O
= 2,29 µF
Temperature / inclination – sensor
circuits
In intrinsically safe level of protection: II 2 G EEx ia
IIB with following maximum values:
U
O
= 16,8 V
I
O
= 251 mA
P
O
= 1 W
Characteristic: linear
Max. permissible external inductance
L
O
= 2,5 mH
Max. permissible external capacitance
C
O
= 2,29 µF
Namur sensor circuits: In intrinsically safe level of protection: II 2 G EEx ia
IIB with following maximum values:
U
O
= 16,8 V
I
O
= 47 mA
P
O
= 198 m W
Characteristic: linear
Max. permissible external inductance
L
O
= 60 mH
Max. permissible external capacitance
C
O
= 2,29 µF
EC-Type Examination Certicate
Number
TÜV 05 ATEX 2969
MultiLevel Instruction Manual Technical Data
