MultiLevel Instruction Manual Installation of the mechanical level sensor components
6.3. Structure of the sensor head
Figure 25: Structure of the sensor head (Drawing 71.251579)
Flanges of type TW220 DN65 are required for the installation of the level
The part numbers are shown on the assembly drawings in the appendix.
6.4. Definition of the Sensor Length
Figure 26: Sensor length (Drawing 25531.351851)
