12.1.3. Inclination sensor type LLGIS
MultiLevel Instruction Manual Technical Data
Measuring circuit (prefabricated
cable):
In intrinsically safe level of protection: II 2 G EEx ia
IIB/IIA with following maximum values:
U
O
= 17 V
I
O
= 260 mA
P
O
= 1,1 W
C
O
= 5 nF
L
O
= 0,25 mH
Maximum permissible ambient
temperature:
+60 °C
EC-Type Examination Certicate
Number:
TÜV 05 ATEX 2868
12.1.4. Temperature sensor type LLGDTS-2
Measuring circuit (prefabricated
cable):
In intrinsically safe level of protection: II 2 G EEx ia
IIB/IIA with following maximum values:
U
O
= 17 V
I
O
= 260 mA
P
O
= 1,1 W
C
O
= 5 nF
L
O
= 0,25 mH
Maximum permissible ambient
temperature:
+60 °C
EC-Type Examination Certicate
Number:
TÜV 05 ATEX 2867
12.1.5. Level Sensor Interface
Power supply: 24V DC nominal voltage
(operating range from 15....30V DC ) under 30
Watt, from built-in battery of corresponding vehicle,
protected against overvoltage (>60V)
CAN bus circuit, internal: 

Level sensor circuit: In intrinsically safe level of protection: II 2 G EEx ia
IIB with following maximum values:
U
O
= 7,14 V
I
O
= 42 mA
P
O
= 75 mW
Characteristic: linear
Max. permissible external inductance
L
O
= 70 mH
Max. permissible external capacitance
C
O
= 260 µF
Input circuit: In intrinsically safe level of protection: II 2 G EEx ia
IIB with following maximum values:
U
O
= 7,14 V
I
O
= 18 mA
P
O
= 32 mW
Characteristic: linear
Max. permissible external inductance
L
O
= 300 mH
Max. permissible external capacitance
C
O
= 260 µF
Permissible ambient temperature
range:
-20 °C to +60 °C
EC-Type Examination Certicate
Number:
TÜV 00 ATEX 1603
